Description
Marque: HELLA
Numéro de pièce fabricant (MPN): 8DB 355 008-351
Contenu du coffret: Set d'essieu (4 plaquettes de frein)
Côté d'assemblage: Essieu avant
Indicateur d'usure: non préparé pour indicateur d'usure
Hauteur 1 (mm): 50,7
Hauteur 2 (mm): 50,2
Largeur 2 (mm): 141,6
Largeur 1 (mm): 141,6
Épaisseur (mm): 15,3
numéro WVA: 21866
Poids (kg): 1,18
Numéro d'information technique: T1143
Système de freinage: VW II
Unité quantitative: Set d'essieu
L'état: Neuf
Classification des pièces: pièce de rechange (OEM)
Garantie: 12 mois
Numéro de référence OE: AUDI 1H0698151B, HELLA 21866, 21868, 7569D694, T1143, SEAT 1H0698151B, SKODA 1H0698151B, VW 1H0698151B
Références équivalentes: A.B.S. 37092, 37622, 37650, ABAKUS/LORO/DEPO 231-01-080, ABE C1W035ABE, AISIN BPVW-1005, ASHIKA 50-00-0085, ATE 13.0460-7101.2, AUTOMEGA 120041710, Barum BA2153, BLUE PRINT ADV1842102, BOSCH 0 986 424 449, BRAXIS AA0018, BRECK 21866 00 702 00, BREMBO P 85 031, CHAMPION 571939CH, CIFAM 822-206-2, DAVID VASCO Q1306, Z1306, DELPHI LP1249, DENCKERMANN B110686, DIAMAX N09138, DJ PARTS BP2169, DON PCP1212, Dr!ve+ DP1010.10.0812, FEBI BILSTEIN 16072, FERODO FDB1288, FSL1288, FOMAR Friction FO 682581, FRIGAIR PD10.516, FTE 9010232, BL1525A1, GIRLING 6113062, HELLA 8DB 355 008-351, HELLA PAGID 8DB 355 008-351, ICER 181178, JAPANPARTS PA-0085AF, JAPKO 500085, JP GROUP 1163600810, 1163600819, JPN 10H9171-JPN, JURID 571939J, KAMOKA JQ1012576, KAWE 810030, KRAFT 6000345, LPR 05P667, MAGNETI MARELLI 363700201143, 363700485031, 363916060391, 363916061153, MAPCO 6406/2, MASTER-SPORT 13046071012-SET-MS, 13046071012N-SET-MS, MAXGEAR 19-0599, MEHA AUTOMOTIVE MH70176, METELLI 22-0206-2, METZGER 1170072, MEYLE 025 218 6615, 025 218 6615/PD, MINTEX MDB1872, MOTAQUIP LVXL216, MTR 12160786, NK 224743, OPTIMAL 10188, BP-10188, ProfiPower 1B1066, QUARO QP5830, QUINTON HAZELL BP1056, RAICAM RA.0623.2, REMSA 0609.20, 8609.02, 8609.03, 8609.04, RIDEX 402B0189, ROADHOUSE 2609.20, SAMKO 5SP667, SASIC 6216051, STARK SKBK-1090186, SKBP-0010189, SWAG 30 91 6072, TEXTAR 2186601, TOMEX brakes TX 10-851, TRISCAN 8110 29017, TRUSTING 215.2, TRW GDB1306, VAICO V10-8108, V10-8108-1, VALEO 301403, 598403, VIKA 66980004701, ZIMMERMANN 21866.150.1
Le tableau de compatibilité n'est donné qu'à titre indicatif et ne garantit pas que cette pièce convienne à votre voiture. Les constructeurs automobiles utilisent différentes variantes d'une même pièce pour un même modèle en fonction de nombreux facteurs tels que : l'année de production, l'usine où la voiture a été assemblée, l'équipement supplémentaire ou le pack ajouté lors de la commande de la voiture, etc. Les différentes variantes ne sont généralement pas interchangeables entre elles. Vérifiez le numéro de la pièce d'origine (OE) utilisée dans votre voiture et comparez-le avec le numéro de référence OE fourni ci-dessus ou contactez-nous pour vérifier la compatibilité.
POUR LES VÉHICULES SUIVANTS:
Modèle | Moteur / kw/CH | Années de production | Restriction
• SEAT Cordoba Berline (6K1, 6K2) 1.0 | AVZ / 51KW/69CH | 06.2001 - 08.2002 | pour numéro PR 1LG
• SEAT Cordoba Berline (6K1, 6K2) 1.0 i | ANV / 37KW/50CH | 09.1996 - 10.2002 |
• SEAT Cordoba Berline (6K1, 6K2) 1.4 | ANX / 40KW/54CH | 12.1997 - 04.1999 |
• SEAT Cordoba Berline (6K1, 6K2) 1.4 16V | APE / 55KW/75CH | 05.2000 - 10.2002 |
• SEAT Cordoba Berline (6K1, 6K2) 1.4 i | AKV / 44KW/60CH | 06.1994 - 10.2002 |
• SEAT Cordoba Berline (6K1, 6K2) 1.4 i 16V | AQQ / 74KW/101CH | 09.1996 - 10.2002 |
• SEAT Cordoba Berline (6K1, 6K2) 1.6 i | 1F / 55KW/75CH | 05.1994 - 06.1999 |
• SEAT Cordoba Berline (6K1, 6K2) 1.6 i | AFT / 74KW/101CH | 07.1996 - 10.2002 | pour numéro PR 1LM
• SEAT Cordoba Berline (6K1, 6K2) 1.8 i | ACC / 66KW/90CH | 02.1993 - 09.2002 |
• SEAT Cordoba Berline (6K1, 6K2) 1.9 D | 1Y / 47KW/64CH | 01.1996 - 08.1996 |
• SEAT Cordoba Berline (6K1, 6K2) 1.9 D | 1Y / 50KW/68CH | 02.1993 - 08.1996 |
• SEAT Cordoba Berline (6K1, 6K2) 1.9 SDI | AEY / 47KW/64CH | 08.1996 - 06.1999 |
• SEAT Cordoba Berline (6K1, 6K2) 1.9 SDI | AQM / 50KW/68CH | 06.1999 - 10.2002 | pour numéro PR 1LG
• SEAT Cordoba Berline (6K1, 6K2) 1.9 TD | AAZ / 55KW/75CH | 02.1993 - 08.1996 |
• SEAT Cordoba Vario (6K5) 1.4 16V | APE / 55KW/75CH | 06.1999 - 12.2002 | pour numéro PR 1LG
• SEAT Cordoba Vario (6K5) 1.4 i | AKV / 44KW/60CH | 09.1996 - 12.2002 | pour numéro PR 1LG
• SEAT Cordoba Vario (6K5) 1.6 i | ABU / 55KW/75CH | 09.1996 - 12.2002 | pour numéro PR 1LG
• SEAT Cordoba Vario (6K5) 1.6 i | 1F / 55KW/75CH | 05.1997 - 06.1999 | pour numéro PR 1LG
• SEAT Cordoba Vario (6K5) 1.6 i | AFT / 74KW/101CH | 09.1996 - 12.2002 | pour numéro PR 1LG
• SEAT Cordoba Vario (6K5) 1.9 SDI | AEY / 47KW/64CH | 09.1996 - 06.1999 | pour numéro PR 1LG
• SEAT Cordoba Vario (6K5) 1.9 SDI | AQM / 50KW/68CH | 06.1999 - 12.2002 | Année jusqu'à 08/2002, pour numéro PR 1LG
• SEAT Ibiza II (6K1) 1.0 16V | AVZ / 51KW/69CH | 10.1999 - 02.2002 | pour numéro PR 1LG
• SEAT Ibiza II (6K1) 1.3 i | 2G / 40KW/54CH | 03.1993 - 08.1999 |
• SEAT Ibiza II (6K1) 1.4 | ANX / 40KW/54CH | 12.1997 - 04.1999 |
• SEAT Ibiza II (6K1) 1.4 16V | APE / 55KW/75CH | 05.2000 - 02.2002 | pour numéro PR 1LG
• SEAT Ibiza II (6K1) 1.4 i | AKV / 44KW/60CH | 09.1993 - 02.2002 |
• SEAT Ibiza II (6K1) 1.4 i 16V | AQQ / 74KW/101CH | 06.1997 - 02.2002 |
• SEAT Ibiza II (6K1) 1.6 i | ABU / 55KW/75CH | 03.1993 - 02.2002 |
• SEAT Ibiza II (6K1) 1.6 i | 1F / 55KW/75CH | 09.1994 - 06.1999 |
• SEAT Ibiza II (6K1) 1.6 i | AFT / 74KW/101CH | 04.1996 - 02.2002 | pour numéro PR 1LM
• SEAT Ibiza II (6K1) 1.8 i | ACC / 66KW/90CH | 03.1993 - 08.1999 |
• SEAT Ibiza II (6K1) 1.9 D | 1Y / 47KW/64CH | 04.1993 - 06.1999 |
• SEAT Ibiza II (6K1) 1.9 SDI | AEY / 47KW/64CH | 08.1996 - 08.1999 |
• SEAT Ibiza II (6K1) 1.9 SDI | AQM / 50KW/68CH | 08.1999 - 02.2002 | pour numéro PR 1LG
• SEAT Ibiza II (6K1) 1.9 TD | AAZ / 55KW/75CH | 03.1993 - 08.1996 |
• SEAT Ibiza II (6K1) 2.0 i 16V | ABF / 110KW/150CH | 08.1996 - 08.1999 | pour numéro PR 1LG
• SEAT TOLEDO I (1L) 1.6 i | 1F / 52KW/71CH | 05.1991 - 12.1993 |
• SEAT TOLEDO I (1L) 1.6 i | EZ / 54KW/73CH | 05.1991 - 03.1999 |
• SEAT TOLEDO I (1L) 1.6 i | 1F / 55KW/75CH | 01.1993 - 03.1999 |
• SEAT TOLEDO I (1L) 1.6 i | AFT / 74KW/101CH | 11.1996 - 03.1999 |
• SEAT TOLEDO I (1L) 1.8 i | RP / 65KW/88CH | 05.1991 - 12.1996 |
• SEAT TOLEDO I (1L) 1.8 i | ACC / 66KW/90CH | 11.1993 - 12.1996 |
• SEAT TOLEDO I (1L) 1.9 D | 1Y / 47KW/64CH | 12.1995 - 03.1999 |
• SEAT TOLEDO I (1L) 1.9 D | 1Y / 50KW/68CH | 05.1991 - 03.1999 |
• SEAT TOLEDO I (1L) 1.9 TD | AAZ / 55KW/75CH | 05.1991 - 03.1999 |
• VW Golf III (1H1) 1.4 | AEX / 40KW/55CH | 11.1991 - 08.1997 | Année à partir de 10/1996
• VW Golf III (1H1) 1.4 | AEX / 44KW/60CH | 10.1991 - 08.1997 | Année à partir de 10/1996
• VW Golf III (1H1) 1.6 | ABU / 55KW/75CH | 09.1992 - 08.1997 | Année à partir de 10/1996
• VW Golf III (1H1) 1.9 D | 1Y / 47KW/64CH | 11.1991 - 08.1997 | Année à partir de 10/1996
• VW Golf III (1H1) 1.9 SDI | AEY / 47KW/64CH | 07.1995 - 08.1997 |
• VW Golf III (1H1) 1.9 TD, GTD | AAZ / 55KW/75CH | 11.1991 - 08.1997 | Année à partir de 10/1996
• VW Golf III Variant (1H5) 1.4 | AEX / 40KW/55CH | 07.1993 - 04.1999 | Année à partir de 10/1996
• VW Golf III Variant (1H5) 1.4 | AEX / 44KW/60CH | 07.1993 - 04.1999 | Année à partir de 10/1996
• VW Golf III Variant (1H5) 1.9 D | 1Y / 47KW/64CH | 07.1993 - 04.1999 | Année à partir de 10/1996
• VW Golf III Variant (1H5) 1.9 SDI | AEY / 47KW/64CH | 07.1995 - 04.1999 |
• VW Golf III Variant (1H5) 1.9 TD | AAZ / 55KW/75CH | 07.1993 - 04.1999 | Année à partir de 10/1996
• VW Polo Classic (6V2) 1.4 | AGY / 62KW/84CH | 05.1996 - 07.2002 | pour numéro PR 1LG, 1ZD
• VW Polo Classic (6V2) 1.6 | AKL / 65KW/88CH | 05.1996 - 09.2001 | pour numéro PR 1LG, 1ZD
• VW Polo Classic (6V2) 1.8 | USD / 75KW/102CH | 06.1998 - 12.2003 | pour numéro PR 1LG
• VW Polo Classic (6V2) 1.8 | USF / 77KW/105CH | 03.1998 - 05.2001 | pour numéro PR 1LG
• VW Polo Classic (6V2) 1.9 SDI | AEY / 48KW/65CH | 06.1996 - 09.2001 | pour numéro PR 1LG, 1ZD
• VW Polo Classic (6V2) 1.9 TDI | AHU / 67KW/91CH | 01.1997 - 08.1999 | pour numéro PR 1LG, 1ZD
• VW Polo Classic (6V2) 100 1.6 | APF / 74KW/100CH | 12.1995 - 09.2001 | pour numéro PR 1LG, 1ZD
• VW Polo Classic (6V2) 110 1.9 TDI | AFN / 81KW/110CH | 06.1998 - 01.2002 | pour numéro PR 1LG, 1ZD
• VW Polo Classic (6V2) 2.0 | ADC / 81KW/110CH | 01.2002 - 12.2003 | pour numéro PR 1LG, 1ZD
• VW Polo Classic (6V2) 2.0 | ADC / 85KW/116CH | 08.1999 - 09.2001 | pour numéro PR 1LG, 1ZD
• VW Polo Classic (6V2) 54 1.4 | ANX / 40KW/54CH | 01.1998 - 08.1999 | pour numéro PR 1LG, 1ZD
• VW Polo Classic (6V2) 57 1.7 SDI | AKW / 42KW/57CH | 07.1997 - 09.2001 | pour numéro PR 1LG, 1ZD
• VW Polo Classic (6V2) 60 1.4 | ANW / 44KW/60CH | 12.1995 - 09.2001 | pour numéro PR 1LG, 1ZD
• VW Polo Classic (6V2) 64 1,9 D | 1Y / 47KW/64CH | 01.1996 - 10.1996 | pour numéro PR 1LG, 1ZD
• VW Polo Classic (6V2) 64 1.9 SDI | AEY / 47KW/64CH | 12.1995 - 08.1999 | pour numéro PR 1LG, 1ZD
• VW Polo Classic (6V2) 68 1.9 SDI | AQM / 50KW/68CH | 08.1999 - 01.2002 | pour numéro PR 1LG, 1ZD
• VW Polo Classic (6V2) 75 1.4 16V | AUA / 55KW/75CH | 10.1999 - 09.2001 | pour numéro PR 1LG, 1ZD
• VW Polo Classic (6V2) 75 1.6 | AEE / 55KW/75CH | 11.1995 - 09.2001 | pour numéro PR 1LG, 1ZD
• VW Polo Classic (6V2) 75 1.6 | 1F / 55KW/75CH | 11.1995 - 09.1997 | pour numéro PR 1LG, 1ZD
• VW Polo Classic (6V2) 90 1.8 | ADZ / 66KW/90CH | 01.1997 - 09.2001 | pour numéro PR 1LG, 1ZD
• VW Polo Classic (6V2) 90 1.9 TDI | AGR / 66KW/90CH | 09.1996 - 09.2001 | pour numéro PR 1LG, 1ZD
• VW Polo PLAYA 1.4 | AGY / 62KW/84CH | 05.1996 - 07.2002 |
• VW Polo Variant (6V5) 1.4 | ANX / 40KW/54CH | 01.1998 - 08.1999 | pour numéro PR 1LG, 1ZD
• VW Polo Variant (6V5) 1.4 | ANW / 44KW/60CH | 05.1997 - 09.2001 | pour numéro PR 1LG, 1ZD
• VW Polo Variant (6V5) 1.4 16V | AUA / 55KW/75CH | 10.1999 - 09.2001 | pour numéro PR 1LG, 1ZD
• VW Polo Variant (6V5) 1.6 | AEE / 55KW/75CH | 05.1997 - 09.2001 | pour numéro PR 1LG, 1ZD
• VW Polo Variant (6V5) 1.7 SDI | AKW / 42KW/57CH | 08.1997 - 09.2001 | pour numéro PR 1LG, 1ZD
• VW Polo Variant (6V5) 1.9 SDI | AEY / 47KW/64CH | 06.1997 - 09.2001 | pour numéro PR 1LG, 1ZD
• VW Polo Variant (6V5) 1.9 SDI | AQM / 50KW/68CH | 08.1999 - 09.2001 | pour numéro PR 1LG, 1ZD
• VW Vento (1H2) 1.4 | AEX / 40KW/55CH | 11.1991 - 09.1998 | Année à partir de 10/1996
• VW Vento (1H2) 1.4 | AEX / 44KW/60CH | 11.1991 - 09.1998 | Année à partir de 10/1996
• VW Vento (1H2) 1.9 D | 1Y / 48KW/65CH | 11.1991 - 09.1998 | Année à partir de 10/1996
• VW Vento (1H2) 1.9 SDI | AEY / 47KW/64CH | 04.1997 - 09.1998 |
