Description
Marque: DELPHI
Numéro de pièce fabricant (MPN): LP3288
Contenu du coffret: Set d'essieu (4 plaquettes de frein)
Côté d'assemblage: Essieu arrière
Indicateur d'usure: préparé pour indicateur d'usure
Hauteur 1 (mm): 52,4
Hauteur 2 (mm): 54,6
Largeur 2 (mm): 122,8
Largeur 1 (mm): 122,9
Épaisseur 1 (mm): 17,5
Épaisseur 2 (mm): 17,5
numéro WVA: 25282 24254
Marque de conformité: E9 90R-02A0825/4769
Information additionnelle: avec tôle anti-bruit
Information additionnelle: sans accessoires
Système de freinage: Continental
Code FMSI: D1341-8452
Matériau de garniture de frottement: Low-Metallic
Unité quantitative: Set d'essieu
L'état: Neuf
Classification des pièces: pièce de rechange (Aftermarket)
Garantie: 12 mois
Numéro de référence OE: MERCEDES-BENZ 0054204920, 0054205120, 0074206120, A0054204920, A0054205120, A0074206120
Références équivalentes: A.B.S. 37585, 37892, ABAKUS/LORO/DEPO 231-02-069, ABE C2M031ABE, C2M031ABE-P, AISIN BPMB-2002, BPMB-2018, ASHIKA 51-00-0505, ATE 13.0460-7257.2, 13.0470-7257.2, BLUE PRINT ADU174204, BOSCH 0 986 494 162, 0 986 495 105, BRECK 24253 00 702 00, BREMBO P 50 104, BSG BSG 60-200-029, BSG 60-202-012, CHAMPION 573248CH, 573735CH, CIFAM 822-666-0, 822-666-2, DAVID VASCO Z2051, DELPHI LP2029, LP3288, DENCKERMANN B110953, Dr!ve+ DP1010.10.0532, FEBI BILSTEIN 16736, FERODO FDB1980, FDB4220, FOMAR Friction FO 931281, FTE BL2076A2, GH GH-412344, HELLA 8DB 355 016-281, HELLA PAGID 8DB 355 016-281, JAPANPARTS PP-0505AF, JAPKO 510505, JP GROUP 1363702310, JURID 573248J, 573248J-AS, 573248JC, 573735J, KAMOKA JQ101117, KRAFT 6011016, LPR 05P1528, 05P1528A, MAGNETI MARELLI 363700450104, 363916060314, 363916061159, MAPCO 6864, 6864HPS, MASTER-SPORT 13046072572N-SET-MS, MAXGEAR 19-1477, METELLI 22-0666-0, METZGER 1170132, MEYLE 025 242 5317, 025 242 5317/PD, 025 242 5418, 025 242 5418/PD, MINTEX MDB3247, MOTAQUIP LVXL1425, NK 223368, OPEN PARTS BPA1305.00, OPTIMAL 12448, BP-12448, BP-12515, QUARO QP1600, QP1600C, QP5857C, QUINTON HAZELL BP1582, RAICAM RA.0880.0, REMSA 1305.00, 1305.20, RIDEX 402B0245, RIDEX PLUS 402B0245P, ROADHOUSE 21305.00, 21305.20, SAMKO 5SP1528, 5SP1528A, SASIC 6216185, SKF VKBP 90114, STARK SKBP-0010245, SWAG 10 91 6736, TEXTAR 2425401, 2425481, TOMEX brakes TX 16-01, TX 17-39, TOPRAN 401 667, TRISCAN 8110 23061, TRUCKTEC AUTOMOTIVE 02.35.234, TRUSTING 682.0, 682.2, TRW GDB1738, GDB1738DTE, GDB2051, GDB2051DTE, VAICO V30-1445, V30-1697, V30-8205, VALEO 302121, 302738, 601051, ZEKKERT BS-1938, ZIMMERMANN 24253.175.1, 24253.975.1
Le tableau de compatibilité n'est donné qu'à titre indicatif et ne garantit pas que cette pièce convienne à votre voiture. Les constructeurs automobiles utilisent différentes variantes d'une même pièce pour un même modèle en fonction de nombreux facteurs tels que : l'année de production, l'usine où la voiture a été assemblée, l'équipement supplémentaire ou le pack ajouté lors de la commande de la voiture, etc. Les différentes variantes ne sont généralement pas interchangeables entre elles. Vérifiez le numéro de la pièce d'origine (OE) utilisée dans votre voiture et comparez-le avec le numéro de référence OE fourni ci-dessus ou contactez-nous pour vérifier la compatibilité.
POUR LES VÉHICULES SUIVANTS:
Modèle | Moteur / kw/CH | Années de production | Restriction
• MERCEDES-BENZ Classe C Berline (W204) C 180 CGI (204.049) | M 271.820 / 115KW/156CH | 01.2007 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 180 Kompressor (204.044, 204.045) | M 271.910 / 115KW/156CH | 01.2008 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 180 Kompressor (204.046) | M 271.952 / 115KW/156CH | 01.2007 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 200 CDI (204.007, 204.006) | OM 646.812 / 100KW/136CH | 01.2007 - 12.2009 |
• MERCEDES-BENZ Classe C Berline (W204) C 200 CGI (204.048) | M 271.820 / 135KW/184CH | 01.2007 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 200 Kompressor (204.041) | M 271.950 / 135KW/184CH | 01.2007 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 220 CDI (204.002) | OM 651.911 / 125KW/170CH | 12.2008 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 220 CDI (204.008) | OM 646.811 / 125KW/170CH | 01.2007 - 11.2008 |
• MERCEDES-BENZ Classe C Berline (W204) C 230 (204.052) | M 272.921 / 150KW/204CH | 01.2007 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 230 4-matic (204.085) | M 272.911 / 150KW/204CH | 07.2007 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 250 CDI (204.003) | OM 651.911 / 150KW/204CH | 08.2008 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 250 CDI 4-matic (204.082) | OM 651.912 / 150KW/204CH | 01.2011 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 250 CGI (204.047) | M 271.860 / 150KW/204CH | 07.2009 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 280 (204.054) | M 272.947 / 170KW/231CH | 01.2007 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 280 4-matic (204.081) | M 272.948 / 170KW/231CH | 07.2007 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 300 (204.054) | M 272.947 / 170KW/231CH | 07.2009 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 300 4-matic (204.081) | M 272.948 / 170KW/231CH | 07.2007 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 300 CDI 4-matic (204.092) | OM 642.832 / 170KW/231CH | 01.2011 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 320 CDI (204.022) | OM 642.960 / 165KW/224CH | 01.2007 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 320 CDI 4-matic (204.089) | OM 642.961 / 165KW/224CH | 07.2007 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 350 (204.056) | M 272.961 / 200KW/272CH | 01.2007 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 350 4-matic (204.087) | M 272.971 / 200KW/272CH | 07.2007 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 350 CDI (204.022) | OM 642.960 / 165KW/224CH | 07.2009 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 350 CDI (204.023) | OM 642.834 / 195KW/265CH | 06.2011 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 350 CDI (204.025) | OM 642.830 / 170KW/231CH | 10.2009 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 350 CDI 4-matic (204.089) | OM 642.961 / 165KW/224CH | 07.2009 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 350 CDI 4-matic (204.092) | OM 642.832 / 170KW/231CH | 10.2009 - 01.2014 |
• MERCEDES-BENZ Classe C Berline (W204) C 350 CGI (204.065) | M 272.982 / 215KW/292CH | 09.2008 - 01.2014 |
• MERCEDES-BENZ Classe C Break (S204) C 180 CGI (204.249) | M 271.820 / 115KW/156CH | 11.2009 - 08.2014 |
• MERCEDES-BENZ Classe C Break (S204) C 180 Kompressor (204.245) | M 271.910 / 115KW/156CH | 01.2008 - 08.2014 |
• MERCEDES-BENZ Classe C Break (S204) C 180 Kompressor (204.246) | M 271.952 / 115KW/156CH | 08.2007 - 08.2014 |
• MERCEDES-BENZ Classe C Break (S204) C 200 CDI (204.207) | OM 646.811 / 100KW/136CH | 08.2007 - 12.2009 |
• MERCEDES-BENZ Classe C Break (S204) C 200 CGI (204.248) | M 271.820 / 135KW/184CH | 08.2007 - 08.2014 |
• MERCEDES-BENZ Classe C Break (S204) C 200 Kompressor (204.241) | M 271.950 / 135KW/184CH | 08.2007 - 08.2014 |
• MERCEDES-BENZ Classe C Break (S204) C 220 CDI (204.202) | OM 651.911 / 125KW/170CH | 12.2008 - 08.2014 |
• MERCEDES-BENZ Classe C Break (S204) C 220 CDI (204.208) | OM 646.811 / 125KW/170CH | 08.2007 - 11.2008 |
• MERCEDES-BENZ Classe C Break (S204) C 230 (204.252) | M 272.921 / 150KW/204CH | 08.2007 - 08.2014 |
• MERCEDES-BENZ Classe C Break (S204) C 250 CDI (204.203) | OM 651.911 / 150KW/204CH | 01.2009 - 08.2014 |
• MERCEDES-BENZ Classe C Break (S204) C 250 CDI 4-matic (204.282) | OM 651.912 / 150KW/204CH | 04.2010 - 08.2014 | Année jusqu'à 01/2014
• MERCEDES-BENZ Classe C Break (S204) C 280 (204.254) | M 272.947 / 170KW/231CH | 08.2007 - 08.2014 |
• MERCEDES-BENZ Classe C Break (S204) C 300 CDI 4-matic (204.292) | OM 642.832 / 170KW/231CH | 06.2011 - 08.2014 |
• MERCEDES-BENZ Classe C Break (S204) C 320 CDI (204.222) | OM 642.960 / 165KW/224CH | 08.2007 - 08.2014 |
• MERCEDES-BENZ Classe C Break (S204) C 320 CDI 4-matic (204.289) | OM 642.961 / 165KW/224CH | 08.2007 - 12.2011 |
• MERCEDES-BENZ Classe C Break (S204) C 350 (204.256) | M 272.961 / 200KW/272CH | 08.2007 - 08.2014 |
• MERCEDES-BENZ Classe C Break (S204) C 350 CDI (204.225) | OM 642.830 / 165KW/224CH | 08.2007 - 08.2014 |
• MERCEDES-BENZ Classe C Break (S204) C 350 CDI (204.225) | OM 642.830 / 170KW/231CH | 10.2009 - 08.2014 |
• MERCEDES-BENZ Classe C Break (S204) C 350 CDI 4-matic (204.289) | OM 642.961 / 165KW/224CH | 08.2007 - 12.2011 |
• MERCEDES-BENZ Classe C Break (S204) C 350 CDI 4-matic (204.292) | OM 642.832 / 170KW/231CH | 10.2009 - 08.2014 |
• MERCEDES-BENZ Classe E Berline (W212) E 220 BlueTEC (212.001) | OM 651.924 / 130KW/177CH | 05.2014 - 12.2015 |
• MERCEDES-BENZ Classe E Décapotable (A207) E 350 BlueTEC (207.426) | OM 642.838 / 185KW/252CH | 06.2013 - 12.2016 |
• MERCEDES-BENZ Classe E Décapotable (A207) E 350 BlueTEC/ d (207.426) | OM 642.838 / 190KW/258CH | 05.2014 - 12.2016 |
• MERCEDES-BENZ Classe E Décapotable (A207) E 350 CDI (207.422) | OM 642.836 / 170KW/231CH | 01.2010 - 12.2011 |
• MERCEDES-BENZ Classe E Décapotable (A207) E 350 CDI (207.423) | OM 642.838 / 195KW/265CH | 04.2011 - 12.2013 |
• MERCEDES-BENZ Classe E Décapotable (A207) E 350 CGI (207.457) | M 272.982 / 215KW/292CH | 01.2010 - 12.2014 |
• MERCEDES-BENZ Classe E Décapotable (A207) E 500 (207.473) | M 278.922 / 300KW/408CH | 09.2011 - 12.2016 |
• MERCEDES-BENZ Classe E Coupe (C207) E 350 BlueTEC (207.326) | OM 642.838 / 185KW/252CH | 06.2013 - 12.2016 |
• MERCEDES-BENZ Classe E Coupe (C207) E 350 BlueTEC / d (207.326) | OM 642.838 / 190KW/258CH | 05.2014 - 12.2016 |
• MERCEDES-BENZ Classe E Coupe (C207) E 350 CDI (207.322) | OM 642.836 / 170KW/231CH | 01.2009 - 06.2011 |
• MERCEDES-BENZ Classe E Coupe (C207) E 350 CDI (207.323) | OM 642.838 / 195KW/265CH | 06.2011 - 06.2013 |
• MERCEDES-BENZ Classe E Coupe (C207) E 350 CGI (207.357) | M 272.982 / 215KW/292CH | 01.2009 - 12.2011 |
• MERCEDES-BENZ GLK (X204) 200 (204.934) | M 274.920 / 135KW/184CH | 08.2013 - 06.2015 |
• MERCEDES-BENZ GLK (X204) 200 CDI (204.901) | OM 651.916 / 100KW/136CH | 12.2013 - 06.2015 |
• MERCEDES-BENZ GLK (X204) 200 CDI (204.901) | OM 651.913 / 105KW/143CH | 07.2010 - 06.2015 |
• MERCEDES-BENZ GLK (X204) 220 CDI (204.902) | OM 651.916 / 120KW/163CH | 12.2008 - 06.2015 |
• MERCEDES-BENZ GLK (X204) 220 CDI (204.902) | OM 651.916 / 125KW/170CH | 12.2008 - 06.2015 |
• MERCEDES-BENZ GLK (X204) 220 CDI 4-matic (204.984) | OM 651.912 / 120KW/163CH | 12.2008 - 06.2015 |
• MERCEDES-BENZ GLK (X204) 220 CDI 4-matic (204.984, 204.997) | OM 651.912 / 125KW/170CH | 12.2008 - 06.2015 |
• MERCEDES-BENZ GLK (X204) 250 (204.936) | M 274.920 / 155KW/211CH | 08.2013 - 06.2015 |
• MERCEDES-BENZ GLK (X204) 250 4-matic (204.937) | M 274.920 / 155KW/211CH | 08.2013 - 06.2015 |
• MERCEDES-BENZ GLK (X204) 250 CDI 4-matic (204.982, 204.904) | OM 651.912 / 150KW/204CH | 09.2009 - 06.2015 |
• MERCEDES-BENZ GLK (X204) 280 4-matic (204.981) | M 272.948 / 170KW/231CH | 06.2008 - 06.2009 |
• MERCEDES-BENZ GLK (X204) 300 4-matic (204.981) | M 272.948 / 170KW/231CH | 07.2009 - 12.2015 |
• MERCEDES-BENZ GLK (X204) 300 4-matic (204.990) | M 276.957 / 182KW/248CH | 09.2009 - 12.2015 |
• MERCEDES-BENZ GLK (X204) 300 4-matic (204.990) | M 276.957 / 185KW/252CH | 09.2009 - 06.2015 |
• MERCEDES-BENZ GLK (X204) 320 CDI 4-matic (204.983) | OM 642.961 / 165KW/224CH | 06.2008 - 06.2015 |
• MERCEDES-BENZ GLK (X204) 350 (204.956) | M 272.991 / 200KW/272CH | 04.2009 - 06.2015 |
• MERCEDES-BENZ GLK (X204) 350 4-matic (204.987) | M 272.971 / 200KW/272CH | 06.2008 - 04.2011 |
• MERCEDES-BENZ GLK (X204) 350 4-matic (204.988) | M 276.957 / 225KW/306CH | 06.2008 - 06.2015 |
• MERCEDES-BENZ GLK (X204) 350 CDI 4-matic (204.992) | OM 642.832 / 165KW/224CH | 07.2009 - 01.2010 |
• MERCEDES-BENZ GLK (X204) 350 CDI 4-matic (204.992) | OM 642.832 / 170KW/231CH | 02.2010 - 06.2015 |
• MERCEDES-BENZ GLK (X204) 350 CDI 4-matic (204.993) | OM 642.835 / 195KW/265CH | 07.2012 - 06.2015 |
