Description
Marque: DELPHI
Numéro de pièce fabricant (MPN): LP1425
Contenu du coffret: Set d'essieu (4 plaquettes de frein)
Côté d'assemblage: Essieu avant
Indicateur d'usure: non préparé pour indicateur d'usure
Hauteur 1 (mm): 64,5
Hauteur 2 (mm): 64,5
Largeur 2 (mm): 134,5
Largeur 1 (mm): 134,8
Épaisseur 1 (mm): 20
Épaisseur 2 (mm): 20
numéro WVA: 23022
Marque de conformité: E1 90R-01881/1176
Information additionnelle: avec tôle anti-bruit
Information additionnelle: sans accessoires
Système de freinage: Bosch
Code FMSI: D1253-8371
Matériau de garniture de frottement: Low-Metallic
Unité quantitative: Set d'essieu
L'état: Neuf
Classification des pièces: pièce de rechange (Aftermarket)
Garantie: 12 mois
Numéro de référence OE: DELPHI 23022, MERCEDES-BENZ 0004214110, 0004236110, 0034200120, 0034205420, A0004214110, A0004236110, A0034200120, A0034205420
Références équivalentes: A.B.S. 37095, ABE C1M018ABE, AISIN BPMB-1011, ATE 13.0460-3980.2, Barum BA2091, BLUE PRINT ADU174238, BOSCH 0 986 424 476, 0 986 494 013, 0 986 494 451, BRAXIS AA0232, BRECK 23022 00 703 20, BREMBO P 50 031, BSG BSG 60-200-048, BSG 60-202-025, CHAMPION 571946CH, CIFAM 822-573-0, DAVID VASCO Z1373, DELPHI LP1425, DENCKERMANN B110474, DJ PARTS BP2285, Dr!ve+ DP1010.10.0822, FEBI BILSTEIN 16094, FERODO FDB1304, FSL1304, FVR1304, FOMAR Friction FO 678681, FTE 9010290, BL1680A2, HELLA 8DB 355 008-631, HELLA PAGID 8DB 355 008-631, ICER 141288, IJS GROUP 40-1225FK, JP GROUP 1363602210, 1363602219, JURID 571946J, KAMOKA JQ1012608, KAWE 810044, KRAFT 6001260, LPR 05P672, 05P672A, MAGNETI MARELLI 363700201168, 363700450031, 363710201168, 363916060327, 363916061155, MAPCO 6522, MASTER-SPORT 13046039802-SET-MS, 13046039802N-SET-MS, 202517030, 202517030P, MAXGEAR 19-0571, METELLI 22-0573-0, METZGER 1170303, MEYLE 025 230 2220, 025 230 2220/PD, MINTEX MDB1967, MOTAQUIP LVXL553, MTR MT546, NK 223340, OPTIMAL 10324, BP-10324, PETERS ENNEPETAL 086.322-00A, ProfiPower 1B1163, PROFIT 5000-1304, QUARO QP7037, QP7037C, QUINTON HAZELL BP1096, RAICAM RA.0714.0, REMSA 0701.00, 8701.00, RIDEX 402B0238, ROADHOUSE 2701.00, SAMKO 5SP672, 5SP672A, SASIC 6216119, SKF VKBP 80412, STARK SKBP-0010238, SWAG 10 91 6094, TEXTAR 2302201, TOMEX brakes TX 12-23, TOPRAN 401 286, TRISCAN 8110 23020, TRUCKTEC AUTOMOTIVE 02.35.117, 02.35.123, TRUSTING 589.0, TRW GDB1373, VAICO V30-8155, V30-8155-1, VALEO 302460, 598299, 872022, ZEKKERT BS-1015, ZIMMERMANN 23022.205.1, 23022.205.2
Le tableau de compatibilité n'est donné qu'à titre indicatif et ne garantit pas que cette pièce convienne à votre voiture. Les constructeurs automobiles utilisent différentes variantes d'une même pièce pour un même modèle en fonction de nombreux facteurs tels que : l'année de production, l'usine où la voiture a été assemblée, l'équipement supplémentaire ou le pack ajouté lors de la commande de la voiture, etc. Les différentes variantes ne sont généralement pas interchangeables entre elles. Vérifiez le numéro de la pièce d'origine (OE) utilisée dans votre voiture et comparez-le avec le numéro de référence OE fourni ci-dessus ou contactez-nous pour vérifier la compatibilité.
POUR LES VÉHICULES SUIVANTS:
Modèle | Moteur / kw/CH | Années de production | Restriction
• MERCEDES-BENZ Classe V (W638/2) V 200 (638.214, 638.294) | M 111.948 / 95KW/129CH | 02.1997 - 07.2003 | Année à partir de 01/1999, 08/1997
• MERCEDES-BENZ Classe V (W638/2) V 200 CDI (638.294) | OM 611.980 / 75KW/102CH | 03.1999 - 07.2003 |
• MERCEDES-BENZ Classe V (W638/2) V 220 CDI (638.294) | OM 611.980 / 90KW/122CH | 03.1999 - 07.2003 |
• MERCEDES-BENZ Classe V (W638/2) V 230 (638.234, 638.294) | M 111.978 / 105KW/143CH | 10.1996 - 07.2003 | Année à partir de 01/1999
• MERCEDES-BENZ Classe V (W638/2) V 230 TD (638.274) | OM 601.970 / 72KW/98CH | 09.1996 - 07.2003 | Année à partir de 01/1999
• MERCEDES-BENZ Classe V (W638/2) V 280 (638.244, 638.294) | M 104.900 / 128KW/174CH | 08.1997 - 07.2003 | Année à partir de 01/1999
• MERCEDES-BENZ SPRINTER 2-t Autobus/Autocar (901, 902) 212 D (902.471, 902.472) | OM 602.980 / 90KW/122CH | 02.1995 - 04.2000 |
• MERCEDES-BENZ SPRINTER 2-t Autobus/Autocar (901, 902) 214 (902.071, 902.072, 902.671, 902.672) | M 111.979 / 105KW/143CH | 02.1995 - 05.2006 |
• MERCEDES-BENZ SPRINTER 2-t Autobus/Autocar (901, 902) 214 NGT (902.072, 902.671, 902.672) | M 111.979 / 95KW/129CH | 02.1995 - 05.2006 |
• MERCEDES-BENZ SPRINTER 2-t Camion plate-forme/Châssis (901, 902) 212 D (901.421, 902.412) | OM 602.980 / 90KW/122CH | 02.1995 - 04.2000 | Année à partir de 01/1998
• MERCEDES-BENZ SPRINTER 2-t Camion plate-forme/Châssis (901, 902) 214 (902.011, 902.012, 902.611, 902.612) | M 111.979 / 105KW/143CH | 02.1995 - 05.2006 | Année à partir de 01/1998
• MERCEDES-BENZ SPRINTER 2-t Camionnette (901, 902) 212 D (901.461, 901.462, 902.461, 902.462) | OM 602.980 / 90KW/122CH | 02.1995 - 04.2000 | Année à partir de 01/1998
• MERCEDES-BENZ SPRINTER 2-t Camionnette (901, 902) 214 (901.061, 901.062, 901.661, 901.662, 902.061,... | M 111.979 / 105KW/143CH | 02.1995 - 05.2006 | Année à partir de 01/1998
• MERCEDES-BENZ SPRINTER 2-t Camionnette (901, 902) 214 NGT (901.661, 902.061, 902.062, 902.661, 902.662) | M 111.979 / 95KW/129CH | 02.1995 - 05.2006 |
• MERCEDES-BENZ SPRINTER 3-t Autobus/Autocar (903) 310 D (903.471, 903.472, 903.473) | OM 602.980 / 75KW/102CH | 01.1997 - 12.1999 |
• MERCEDES-BENZ SPRINTER 3-t Autobus/Autocar (903) 312 D 2.9 (903.471, 903.472, 903.473) | OM 602.980 / 90KW/122CH | 02.1995 - 04.2000 |
• MERCEDES-BENZ SPRINTER 3-t Autobus/Autocar (903) 312 D 2.9 4x4 (903.473) | OM 602.980 / 90KW/122CH | 05.1997 - 08.2002 | Année à partir de 01/1998
• MERCEDES-BENZ SPRINTER 3-t Autobus/Autocar (903) 314 (903.071, 903.072, 903.073, 903.671, 903.672,... | M 111.979 / 105KW/143CH | 02.1995 - 05.2006 |
• MERCEDES-BENZ SPRINTER 3-t Autobus/Autocar (903) 314 4x4 (903.672, 903.673) | M 111.984 / 105KW/143CH | 08.2002 - 05.2006 |
• MERCEDES-BENZ SPRINTER 3-t Autobus/Autocar (903) 314 NGT (903.072, 903.671, 903.672) | M 111.979 / 95KW/129CH | 02.1995 - 05.2006 |
• MERCEDES-BENZ SPRINTER 3-t Camion plate-forme/Châssis (903) 312 D 2.9 (903.411, 903.412, 903.421, 903.422, 903.423) | OM 602.980 / 90KW/122CH | 02.1995 - 04.2000 | Année à partir de 01/1998
• MERCEDES-BENZ SPRINTER 3-t Camion plate-forme/Châssis (903) 314 (903.011, 903.012, 903.013, 903.022, 903.612,... | M 111.979 / 105KW/143CH | 02.1995 - 05.2006 | Année à partir de 01/1998
• MERCEDES-BENZ SPRINTER 3-t Camion plate-forme/Châssis (903) 314 4x4 (903.612, 903.613, 903.622) | M 111.984 / 105KW/143CH | 08.2002 - 05.2006 |
• MERCEDES-BENZ SPRINTER 3-t Camion plate-forme/Châssis (903) 314 NGT (903.611, 903.612, 903.613, 903.622, 903.012,... | M 111.979 / 95KW/129CH | 02.1995 - 05.2006 |
• MERCEDES-BENZ SPRINTER 3-t Camionnette (903) 312 D 2.9 (903.461, 903.462, 903.463) | OM 602.980 / 90KW/122CH | 02.1995 - 04.2000 | Année à partir de 01/1998
• MERCEDES-BENZ SPRINTER 3-t Camionnette (903) 312 D 2.9 4x4 (903.461, 903.462) | OM 602.980 / 90KW/122CH | 05.1997 - 08.2002 |
• MERCEDES-BENZ SPRINTER 3-t Camionnette (903) 314 (903.061, 903.062, 903.063, 903.661, 903.662) | M 111.979 / 105KW/143CH | 02.1995 - 05.2006 | Année à partir de 01/1998
• MERCEDES-BENZ SPRINTER 3-t Camionnette (903) 314 4x4 (903.661, 903.662, 903.663) | M 111.984 / 105KW/143CH | 08.2002 - 05.2006 |
• MERCEDES-BENZ SPRINTER 3-t Camionnette (903) 314 NGT (903.661, 903.061, 903.062, 903.063, 903.662) | M 111.979 / 95KW/129CH | 02.1995 - 05.2006 |
• MERCEDES-BENZ SPRINTER 4-t Camion plate-forme/Châssis (904) 408 D | OM 601.943 / 58KW/79CH | 02.1996 - 05.2006 | Année à partir de 01/1998
• MERCEDES-BENZ SPRINTER 4-t Camion plate-forme/Châssis (904) 410 D | OM 602.980 / 75KW/102CH | 02.1996 - 05.2006 |
• MERCEDES-BENZ SPRINTER 4-t Camion plate-forme/Châssis (904) 410 D 4x4 | OM 602.980 / 75KW/102CH | 05.1997 - 05.2006 |
• MERCEDES-BENZ SPRINTER 4-t Camion plate-forme/Châssis (904) 412 D | OM 602.980 / 85KW/115CH | 02.1996 - 05.2006 |
• MERCEDES-BENZ SPRINTER 4-t Camion plate-forme/Châssis (904) 412 D | OM 602.980 / 90KW/122CH | 02.1996 - 05.2006 | Année à partir de 01/1998
• MERCEDES-BENZ SPRINTER 4-t Camion plate-forme/Châssis (904) 412 D 4x4 | OM 602.980 / 85KW/115CH | 05.1997 - 05.2006 |
• MERCEDES-BENZ SPRINTER 4-t Camion plate-forme/Châssis (904) 412 D 4x4 | OM 602.980 / 90KW/122CH | 05.1997 - 05.2006 |
• MERCEDES-BENZ SPRINTER 4-t Camion plate-forme/Châssis (904) 414 (904.012, 904.013, 904.612, 904.613) | M 111.979 / 105KW/143CH | 02.1995 - 05.2006 | Année à partir de 01/1998
• MERCEDES-BENZ SPRINTER 4-t Camion plate-forme/Châssis (904) 414 4x4 (904.012, 904.013, 904.612, 904.613) | M 111.979 / 105KW/143CH | 05.1997 - 05.2006 |
• MERCEDES-BENZ SPRINTER 4-t Camionnette (904) 408 D | OM 601.943 / 58KW/79CH | 02.1996 - 05.2006 | Année à partir de 01/1998
• MERCEDES-BENZ SPRINTER 4-t Camionnette (904) 410 D | OM 602.980 / 75KW/102CH | 02.1996 - 05.2006 |
• MERCEDES-BENZ SPRINTER 4-t Camionnette (904) 410 D 4x4 | OM 602.980 / 75KW/102CH | 05.1997 - 05.2006 |
• MERCEDES-BENZ SPRINTER 4-t Camionnette (904) 412 D | OM 602.980 / 85KW/115CH | 02.1996 - 05.2006 | Année à partir de 01/1998
• MERCEDES-BENZ SPRINTER 4-t Camionnette (904) 412 D | OM 602.980 / 90KW/122CH | 02.1996 - 05.2006 | Année à partir de 01/1998
• MERCEDES-BENZ SPRINTER 4-t Camionnette (904) 412 D 4x4 | OM 602.980 / 85KW/115CH | 05.1997 - 05.2006 |
• MERCEDES-BENZ SPRINTER 4-t Camionnette (904) 412 D 4x4 | OM 602.980 / 90KW/122CH | 05.1997 - 05.2006 |
• MERCEDES-BENZ SPRINTER 4-t Camionnette (904) 414 (904.062, 904.063, 904.662, 904.663) | M 111.979 / 105KW/143CH | 02.1996 - 05.2006 | Année à partir de 01/1998
• MERCEDES-BENZ SPRINTER 4-t Camionnette (904) 414 D 4x4 | OM 602.980 / 90KW/122CH | 05.1997 - 05.2006 |
• MERCEDES-BENZ VITO Autobus/Autocar (W638) 108 CDI 2.2 (638.194) | OM 611.980 / 60KW/82CH | 03.1999 - 07.2003 |
• MERCEDES-BENZ VITO Autobus/Autocar (W638) 108 D 2.3 (638.164) | OM 601.942 / 58KW/79CH | 02.1996 - 07.2003 | Année à partir de 01/1998
• MERCEDES-BENZ VITO Autobus/Autocar (W638) 110 CDI 2.2 (638.194) | OM 611.980 / 75KW/102CH | 03.1999 - 07.2003 |
• MERCEDES-BENZ VITO Autobus/Autocar (W638) 110 TD 2.3 (638.174) | OM 601.970 / 72KW/98CH | 02.1996 - 07.2003 | Année à partir de 01/1998
• MERCEDES-BENZ VITO Autobus/Autocar (W638) 112 CDI 2.2 (638.194) | OM 611.980 / 90KW/122CH | 03.1999 - 07.2003 |
• MERCEDES-BENZ VITO Autobus/Autocar (W638) 113 2.0 (638.114, 638.194) | M 111.948 / 95KW/129CH | 02.1996 - 07.2003 | Année à partir de 01/1998, 08/1997
• MERCEDES-BENZ VITO Autobus/Autocar (W638) 114 2.3 (638.134, 638.194) | M 111.978 / 105KW/143CH | 12.1996 - 07.2003 | Année à partir de 01/1998
• MERCEDES-BENZ VITO Camionnette (W638) 108 CDI 2.2 (638.094) | OM 611.980 / 60KW/82CH | 03.1999 - 07.2003 |
• MERCEDES-BENZ VITO Camionnette (W638) 108 D 2.3 (638.064, 638.068) | OM 601.942 / 58KW/79CH | 03.1997 - 07.2003 | Année à partir de 01/1998
• MERCEDES-BENZ VITO Camionnette (W638) 110 CDI 2.2 (638.094) | OM 611.980 / 75KW/102CH | 03.1999 - 07.2003 |
• MERCEDES-BENZ VITO Camionnette (W638) 110 D 2.3 (638.074, 638.078) | OM 601.970 / 72KW/98CH | 03.1997 - 07.2003 | Année à partir de 01/1998
• MERCEDES-BENZ VITO Camionnette (W638) 112 CDI 2.2 (638.094) | OM 611.980 / 90KW/122CH | 03.1999 - 07.2003 |
• MERCEDES-BENZ VITO Camionnette (W638) 113 2.0 (638.014, 638.094) | M 111.948 / 95KW/129CH | 03.1997 - 07.2003 | Année à partir de 01/1998, 08/1997
• MERCEDES-BENZ VITO Camionnette (W638) 114 2.3 (638.034, 638.094) | M 111.978 / 105KW/143CH | 03.1997 - 07.2003 | Année à partir de 01/1998
